Nano-crystalline Common Mode Choke Cores

 Nano CMC iron core        Real CMC core has high saturation magnetic induction that can reduce the volume of CMC,outstanding ability to resist unblanced current, excellent impedance and tamperature stability.So it can be used to the inverter circuit ,frequency converter.UPS, switching power,EMC filter and new energy. High performance nano CMC iron core Item Index Magnetic saturation induction intensity Bs(T) 1.2 Curie temperature Tc(℃) 570 Stacking factor(k) ≥0.8 Initial permeability 85000 Permeability μ(10kHz) 80000 Permeability μ(100kHz) 20000 Resistivity δ(μΩ▪cm) ≥130 Density ρ(g/cm3) 7.2…
