1.14inch TFT dots, IPS type 4line SPI interface

Model Number: N114-2413THBIG01-H13 Brand Name: Newvision Origin: China (mainland) Small Orders: Accepted Key Specifications/Special Features: 1 LCD Size 1.14 inch(Diagonal) - 2 Display Mode Normally black - 3 Resolution 135(H)RGB x 240(V) - 4 Dot pitch 0.1101(H) x 0.1038(V) mm - 5 Active area 14.864(H) x 24.912(V) mm - 6 Module size 17.6(H) x 31.0(V) x1.6 (D) mm - 7 Color arrangement RGB Vtertical stripe - 8 Interface 4 Line SPI - 9 Drive IC ST7789V - 10 Luminance(cd/m2) 400 (TYP) 11 Viewing Direction All View 12 Backlight 1 White LED 13 Operating Temp. -20℃~ + 70℃ ℃ 14 Storage Temp. -30℃~+ 80℃ ℃ 15 Weight 1.8 g   Shipping Information: FOB Port: Shenzhen Lead Time: 15 - 20 days HTS Code: 9013.80.90 00 Dimensions per Unit: 1.76 × 3.16 × 0.16 Centimeters Weight per Unit: 2.8 Grams Units per Export…
