CC series Dimmable Driver 15W100-700

The housing is made from V0 flame retardant PC materials from COVESTRO. Small size and light weight. Wide range of applicable lamps. Class 2 LED driver, Safety Extra Low Voltage (SELV). Innovative thermal management technology intelligently protects the life of the LED driver. Overheat, overload, short circuit protection and automatic recovery. Up to 50,000-hour life time. 5-year warranty (AiSHi capacitor).   PRODUCT DESCRIPTION TECHNICAL SPECIFICATIONS HOUSING  CHARACTERISTICS FUNCTIONS Constant Current LED Driver Output Current adjustable via NFC Switch dimmable ：DALI 100-700mA 2.5-46V up to 86-87% Efficiency Life Time 50.000h 5years warranty Input Voltage 220-240VAC Frequency 0/50/60Hz Power Factor ≥0.93 Current ripple (< 120 Hz) ±3% IP Grade IP20 Insulation Class II Built-in/Independent 103.4x30x21mm Overload Protection Short Circuit Protection SELV
