Custom 3 4 5 Axis Milling

The path of the knife, the outer cam first moves the tool to the K point, completes the tool offset and the knife at the iC' point, moves straight to the point a, and then the workpiece is processed a-b-c-d-e-a-K" point, Retreat at K" point. The groove cam adopts the theoretical curve programming, and the groove cam path is the knife at the point A, and then the knife is lifted by A-B-C-D-E-A. The width of the groove is controlled by the G41 tool to the left and the G42 tool to the right. After the milling is finished, a certain amount of grinding is left on the curve, generally 0.4~0.6mm, the groove cam is left 0.1~0.15mm, then heat treatment is performed, the cam surface is quenched, and finally the cam grinding process is performed.            Our Advantages of CNC Machining Our engineers can handle complex and precision parts in several industries without a problem. RongNa has extensive in-house equipment for both manufacturing and t…
