Direct-actuated Flange End Pressure Reducing Valve

Direct-actuated Valve 1. The gate is designed for opening status, which will not influence the water     supply function under unsatble inlet pressure condition. 2. When the outlet pressure responds directly to the pressure control chamber     and adjusts the setting pressure, it responds quickly and adjusts the pressure     accurately. 3. Pressure Adjusting Range:      * 1kgf / cm2~3kgf / cm2     * 2kgf / cm2~5kgf / cm2     * 4kgf / cm2~9kgf / cm2 4. Pressure needed from fully-closed gate to fully-opened gate :     1.5 kgf/cm2 (1 kgf/cm2 = 14.2 psi) 5. Applied Temperature     * -15°C~80°C 6. Maximum Applied Pressure: 12 kgf/cm2
