Rubber Insulated Mining Power Cable 3×2AWG

Rubber Insulated Mining Power Cable Application: Mining cable designed for use as a trailing cable on AC mining power cable equipment. Manufactured standards: ICEA S 75-381   MT818.1-818.9 GB/T12972or the standards agreed by both of the customers and us. Production Scope: Nominal Cross-section:0.811mm2(18AWG)-507mm2(1000kcmil) Rated Voltage:  25kV or below Core Number:  1-9core Portable cable(Flexible conductor) Type W--Without grounding conductors  Type G -- With grounding conductors Type G-GC --With grounding conductors and one ground-check conductor Type G-CGC --With grounding conductors and one ground-check conductor in center Type PG--With single grounding conductors Type PCG--With single grounding conductors and two control conductors Type SH--shielded single conductor Type SHD--with individually shielded(braid) power conductors and grounding conductor Type SHD-GC--w…
