AMK-312

Usable bandwidth (-10 dB)：42 Hz – 20 kHz (K3 70) Maximum SPL1：143 dB (K3 70) Nominal directivity (-6 dB)： Horizontal: 70° / 110° symmetric or 90° asymmetric vertical: depending on number of elements and array curvature LF: 2 × 12″ neodymium cone driver（8 Ω） HF: 1 × 4″ diaphragm compression driver, neodymium（8 Ω） LF: bass-reflex, L-Vents HF: DOSC waveguide, Panflex Connectors：2 × 4-point speakON Rigging and handling： Flush-fitting 4-point rigging system 2 handles inter-enclosure angles: 0.25°, 1°, 2°, 3°, 4°, 5°, 7.5° or 10° Cabinet：Premium grade Baltic birch plywood Front：Coated steel grill acoustically neutral 3D fabric Rigging components：High grade steel with anti-corrosion coating Finish：Dark grey brown Pantone 426 C IP：IP55 Weight (net)：43 kg Size：357mm×403mm×950mm
