modbus rtu ascii to PROFINET adapter

Modbus-RTU ASCll or Non-standard Protocol to PROFINET Converter ODOT-PNM02 V2.1 Modbus （master/slave, RTU/ASCII) to PROFINET, 2 port serial port (RS485/ RS232 / RS422), supports 50 slots, 200 commands in TIA portal (by configured software), support MAX 60 slaves 1.  Supports protocol conversion between Modbus and PROFINET 2.  Supports 2* RS485/RS232 or 1*RS422 3.  Supports Modbus master or slave, and supports RTU or ASCII 4.  Supports working temperature of -40〜85°C 5.  Supports data area: 2 serial Modbus-RTU/ASCII to PROFIBUS gateway with Max. input 1440 bytesand Max. output 1440 bytes 6.  Supports one key reset 7.  ODOT-PNM02 V2.1 supports 60 slaves (200 read and write commands) Technical Parameters Mechanical Property Shell Aluminum alloy Weight 335g Dimension 27.5*110*80mm Working Temperature -40〜85°C Storage Temperature -55〜125°C Relative Humidity 5 〜95% (no condensation) Input Voltage 19.2〜28.8 VDC Wiring 3.81mm plug screw terminal Power Max. 200mA @…
