Space-saving Compact Triple Gear

As a core integrated component of multi-speed transmission systems, the triple gear integrates the functions of three groups of gears with different numbers of teeth through an integrated design, greatly improving the integration of the transmission system. Its advantage of high integration is significant, integrating the power transmission function of the traditional discrete gear set into one, reducing the number of parts by more than 40%, and lowering the assembly complexity and system failure rate. The transmission accuracy comes from the precision processing technology, using five-axis linkage gear milling + grinding processing, the cumulative pitch error is ≤ GB/T 10095.1-2008 grade 6 standard, the tooth surface roughness reaches Ra0.8μm, and the meshing gap is controlled at 0.02-0.04mm, ensuring stable transmission without deviation during multi-speed switching. At the same time, the space-saving feature is prominent, and the integrated structure reduces the axial occupied spa…
